RFS4
HOME / Product
ADVANTAGE
2.4G worldwide applicable
Output contacts 5A load design
In case of losing remote control, or defect,via key on the receiver you still can switch on or off
Wall mounting bracket available
SIZE
Transmitter: L 65 × W 42 × H 8.6 mm
Receiver: L 70 × W 80 × H 15.4 mm
ELECTRICAL AND PHOTOMETRIC CHARACTERISTICS
Transmitter
Frequency | 2.4G |
Working range | 30m |
Working voltage | 3V（CR2032 battery） |
Working current | ＜6mA |
Static current | ＜8uA |
Receiver
Receving Frequency | 2.4G |
Working range | 30m |
Input voltage | DC 12V |
Output power | 60W（max.） |
Single channel load | 15W（max.） |
SPECIFICATION
TX4 Transmitter Key function description
CH1/ON/OFF/DIM | CH2/ON/OFF/DIM | CH3/ON/OFF/DIM | CH4/ON/OFF/DIM | |
SHORT PRESS | ON/OFF | ON/OFF | ON/OFF | ON/OFF |
LONG PRESS | CH1 dimming circulated | CH2 dimming circulated | CH3 dimming circulated | CH4 dimming circulated |
RX4 Receiver Key function description
LONG PRESS 2 SECONDS | LONG PRESS 5 SECONDS | SHORT PRESS |
Learning mode, lights flash, showing learning status | ON | OFF |
